Gersan | 135° Dönüş Elemanı (h=40mm)

135° Dönüş Elemanı (h=40mm)

Kaplama: TS 914 EN ISO-1461 (BS-EN-ISO-1461) Sıcak Daldırma Galvaniz.

Bu ürünler isteğe bağlı olarak Pregalvaniz, Corten-A, Alüminyum ve 304-316 (SS 304-316) Kalite Paslanmaz Sacdan imal edilebilir.

Galeri

Dünyanın kaliteli markalarına Gersan kalitesi ile sorunsuz ulaşın

Teknik Özellikler

Sipariş kodu Stok kodu A
mm
B
mm
T
mm
e
mm
Ağırlık (Kg/ad)
GD-5 – 45 D 1607005019140 54 54 271 1 0,400
GD-10 – 45 D 1607010029140 104 104 271 1,5 0,750
GD-20 – 45 D 1607020029140 205 205 331 1,5 1,600
GD-30 – 45 D 1607030039140 305 305 342 2 3,000
GD-40 – 45 D 1607040039140 405 405 396 2 3,250
GD-50 – 45 D 1607050039140 506 506 457 2 4,950
GD-60 – 45 D 1607060039140 606 606 499 2 5,650
