Gersan | GMI Ladder Middle Reducer H:100

GMI Ladder Middle Reducer H:100

Coating: TS 914 EN ISO-1461 (BS-EN-ISO-1461) Hot Dip Galvanized

These products can be produced from made of Pregalvanized, CORTEN-A, Aluminium and 304-316 (SS 304-316) quality steel sheet optionally.

Technical Catalog

Gallery

Reach the world’s quality brands seamlessly with Gersan quality.

Technical Specifications

Order Code Stock Code A (mm) B (mm) h (mm) t (mm) weight (Kg/unit)
GR-GMI-100/20×10 D 1667201049140 200 100 100 2 1,967
GR-GMI-100/30×20 D 1667302049140 300 200 100 2 2,039
GR-GMI-100/40×30 D 1667403049140 400 300 100 2 2,111
GR-GMI-100/50×40 D 1667504049140 500 400 100 2 2,183
GR-GMI-100/60×50 D 1667605049140 600 500 100 2 2,254
